VLC Part
1 / 5
| Fastener Size | Belt Thickness Range | Mechanical Fastener Ratings Up To: | Minimum Pulley Diameter | |||
|---|---|---|---|---|---|---|
| inch | mm | PIW | KN/m | inch | mm | |
| 1" | 3/16 ---- 7/16 | 5 --- 11 | 150 | 30 | 12 | 300 |
| 140E | 3/16 ---- 7/16 | 5 --- 11 | 225 | 40 | 14 | 360 |
| 190E | 5/16 ---- 9/16 | 8 --- 14 | 375 | 65 | 18 | 460 |
| 1.5" | 7/16 ---- 11/16 | 11 --- 17 | 300 | 50 | 18 | 460 |
| 2" | 9/16 ---- 13/16 | 14 --- 21 | 440 | 75 | 30 | 760 |
| 2.5" | 3/4 ---- 1 | 19 --- 25 | 450 | 75 | 42 | 1070 |
